BB-03PMFP-SC7001
ActiveAmphenol LTW
CERES, STANDARD SIZE, 10A, 03 PI
Deep-Dive with AI
Search across all available documentation for this part.
BB-03PMFP-SC7001
ActiveAmphenol LTW
CERES, STANDARD SIZE, 10A, 03 PI
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | BB-03PMFP-SC7001 |
|---|---|
| Color | Black |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish - Mating | Gold |
| Contact Material | Copper Alloy |
| Current Rating (Amps) | 10 A |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Insert Material | Thermoplastic |
| Mounting Feature | Bulkhead - Front Side Nut |
| Mounting Type | Through Hole, Panel Mount |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Orientation | Keyed |
| Primary Material | Plastic |
| Shell Size - Insert | B |
| Shielding | Unshielded |
| Termination | Solder |
| Voltage Rating | 250 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 10 | $ 6.88 | |
Description
General part information
BB-03PMFP Series
3 Position Circular Connector Receptacle, Female Sockets Solder
Documents
Technical documentation and resources
No documents available
