RSA-3290-10

Active

RF Industries

N FEMALE-SMA FEMALE; BH

Search across all available documentation for this part.

Active

RF Industries

N FEMALE-SMA FEMALE; BH

Technical Specifications

Parameters and characteristics for this part

Specification	RSA-3290-10

Adapter Type	Jack to Jack
Body Finish	Nickel
Body Material	Brass
Center Contact Material	Phosphor Bronze
Center Contact Plating	Gold
Center Gender	Female to Female
Conversion Type	Between Series
Convert From (Adapter End)	Female Socket, SMA Jack
Convert To (Adapter End)	Female Socket, N Jack
Dielectric Material	Polytetrafluoroethylene (PTFE)
Frequency - Max [Max]	11 GHz
Impedance	50 Ohms
Mounting Feature	Flange
Operating Temperature [Max]	165 °C
Operating Temperature [Min]	-65 ░C
Style	Straight

Part	Body Material	Center Contact Material	Mounting Feature	Style	Adapter Type	Frequency - Max [Max]	Convert From (Adapter End)	Convert To (Adapter End)	Impedance	Operating Temperature [Min]	Operating Temperature [Max]	Center Contact Plating	Body Finish	Dielectric Material	Center Gender	Conversion Type
RF Industries RSA-3290-10	Brass	Phosphor Bronze	Flange	Straight	Jack to Jack	11 GHz	Female Socket SMA Jack	Female Socket N Jack	50 Ohms	-65 ░C	165 °C	Gold	Nickel	Polytetrafluoroethylene (PTFE)	Female to Female	Between Series

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adapter Coaxial Connector SMA Jack, Female Socket To N Jack, Female Socket 50 Ohms
