BLVR-L30D-B1NS-N

Active

Amphenol All Sensors Corporation

SENSOR 1.08PSID 0.08" .042V 4SIP

Search across all available documentation for this part.

Active

Amphenol All Sensors Corporation

SENSOR 1.08PSID 0.08" .042V 4SIP

Technical Specifications

Parameters and characteristics for this part

SENSOR 1.08PSID 0.08" .042V 4SIP

Part	Port Style	Mounting Type	Applications	Termination Style	Supplier Device Package	Port Size	Port Size	Port Size	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Output Type	Accuracy	Output [Min]	Output [Max]	Operating Pressure	Operating Pressure	Voltage - Supply	Pressure Type	Maximum Pressure	Maximum Pressure
Amphenol All Sensors Corporation BLVR-L30D-B1NS-N	Barbless	Through Hole	Board Mount	PC Pin	4-SIP	Male, Tube, Dual	0.08 "	2.04 mm	4-SIP, Dual Ports, Same Side	-25 °C	85 °C	Wheatstone Bridge	2 %	0 mV	42 mV	7.48 kPa	1.08 PSI	6 V	Differential	7.23 PSI	49.83 kPa

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 34.95

General part information

Pressure Sensor ±1.08PSI (±7.48kPa) Differential Male - 0.08" (2.04mm) Tube, Dual 0 mV ~ 42 mV (3.3V) 4-SIP, Dual Ports, Same Side
