471+ IW-INDIGO-1/2"X36YD

Active

3M (TC)

TAPE VINYL INDIGO 1/2"X36YDS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

471+ IW-INDIGO-1/2"X36YD

Active

3M (TC)

TAPE VINYL INDIGO 1/2"X36YDS

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	471+ IW-INDIGO-1/2"X36YD

Adhesive	Rubber
Backing, Carrier	Vinyl
Color	Indigo
Length	36 yd
Length	32.9 m
Length	108 ft
Shelf Life	18 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Conformable Vinyl
Thickness	0.0053 "
Thickness	0.135 mm
Thickness	5.3 mils
Usage	General Purpose, Sealing, Coding, Marking
Width	0.5 in
Width	12.7 mm
Width	0.5 in

471 Series

...

Part	Backing, Carrier	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Usage	Adhesive	Shelf Life	Color	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Width	Width	Width	Thickness	Thickness	Thickness	Length	Length	Length	Tape Type	Temperature Range [Max]	Temperature Range [Min]	Shelf Life Start	Storage/Refrigeration Temperature [Max]	Storage/Refrigeration Temperature [Min]	Width [x]	Width [x]	Length [x]	Length [x]	Width [y]	Width [y]	Length [x]	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature
3M (TC) 471Y-0.75-5	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	Yellow	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm	0.75 in	19.05 mm	0.75 in	5.2 mils	0.132 mm	0.0052 "	4.6 m	15 ft	5 yd	Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture
3M (TC) 471-IW-BLACK-1/2"X36YD	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	Black	60 °F	80 °F	4.1 mils	0.0041 "	0.104 mm	0.5 in	0.5 in	12.7 mm	5.2 mils	0.132 mm	0.0052 "	32.9 m	108 ft	36 yd	Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture	27 °C	15 °C
3M (TC) 471-R-3-5	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	Red	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm				5.2 mils	0.132 mm	0.0052 "				Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture			76.2 mm	3 in	5 in	127 mm
3M (TC) 3M 471 2"X10YD WHITE-PERF 12"	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	White	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm				5.2 mils	0.132 mm	0.0052 "				Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture					30 ft	9.1 m	2 "	50.8 mm	10 yds
3M (TC) 471-YELLOW-3/4"X36YD-BOX	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	Yellow	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm	0.75 in	19.05 mm	0.75 in	5.2 mils	0.132 mm	0.0052 "	32.9 m	108 ft	36 yd	Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture
3M (TC) 471-BLACK-1/2"X36YD-BULK	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	Black	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm	0.5 in	0.5 in	12.7 mm	5.2 mils	0.132 mm	0.0052 "	32.9 m	108 ft	36 yd	Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture
3M (TC) 3M 471 2"X10YD WHITE-PERF 24"	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	White	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm				5.2 mils	0.132 mm	0.0052 "				Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture					30 ft	9.1 m	2 "	50.8 mm	10 yds
3M (TC) 471+ IW-INDIGO-1/2"X36YD	Vinyl				Coding General Purpose Marking Sealing	Rubber	18 Months	Indigo						0.5 in	0.5 in	12.7 mm	5.3 mils	0.135 mm	0.0053 "	32.9 m	108 ft	36 yd	Conformable Vinyl			Date of Manufacture										70 °F	21 °C
3M (TC) 471-BLACK-4"X36YD-BULK	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	Black	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm				5.2 mils	0.132 mm	0.0052 "	32.9 m	108 ft	36 yd	Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture			101.6 mm	4 "
3M (TC) 471-RED-3/8"X36YD-BULK	Vinyl	0.028 mm	1.1 mils	0.0011 in	Coding General Purpose Marking Sealing	Rubber	18 Months	Red	16 °C 60 °F	27 °C 80 °F	4.1 mils	0.0041 "	0.104 mm	0.38 in	0.375 in	9.65 mm	5.2 mils	0.132 mm	0.0052 "	32.9 m	108 ft	36 yd	Conformable Vinyl	77 °C 170 °F	4 °C 40 °F	Date of Manufacture

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 19.30
		12	$ 17.55
		36	$ 16.67
		60	$ 15.79
		108	$ 14.92
		252	$ 14.04
		504	$ 13.16

Description

General part information

471 Series

Conformable Vinyl Tape Rubber Adhesive Indigo 0.50" (12.70mm) 1/2" X 108' (32.9m) 36 yds

Documents

Technical documentation and resources
