CD09AR-GY

Active

Sealcon

CABLE GLAND 2.03-6.1MM PG9

Search across all available documentation for this part.

Active

Sealcon

CABLE GLAND 2.03-6.1MM PG9

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CD09AR-GY	CD09AR Series

Color	Gray	Gray, Black
Ingress Protection	IP69K, IP68, NEMA 6	IP69K, IP68, NEMA 6
Material	Polyamide (PA66), Nylon 6/6	Polyamide (PA66), Nylon 6/6
Operating Temperature [Max]	100 °C	100 °C
Operating Temperature [Min]	-40 °C	-40 °C
Outside Cable Diameter (Max) [Max] [diameter]	0.24 in	0.24 in
Outside Cable Diameter (Max) [Max] [diameter]	6.1 mm	6.1 mm
Outside Cable Diameter (Min) [Min] [diameter]	0.08 in	0.08 in
Outside Cable Diameter (Min) [Min] [diameter]	2.03 mm	2.03 mm
Panel Hole Size	15.2 mm	15.2 mm
Panel Hole Size	0.6 in	0.6 in
Thread Length	7.87 mm	7.87 mm
Thread Length	0.31 in	0.31 in
Thread Size	PG9	PG9
Type	Cable Gland	Cable Gland

CABLE GLAND 2.03-6.1MM PG9

Part	Color	Thread Length	Thread Length	Outside Cable Diameter (Max) [Max] [diameter]	Outside Cable Diameter (Max) [Max] [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Material	Outside Cable Diameter (Min) [Min] [diameter]	Outside Cable Diameter (Min) [Min] [diameter]	Thread Size	Type	Panel Hole Size	Panel Hole Size	Ingress Protection
Sealcon CD09AR-GY	Gray	7.87 mm	0.31 in	0.24 in	6.1 mm	100 °C	-40 °C	Polyamide (PA66), Nylon 6/6	0.08 in	2.03 mm	PG9	Cable Gland	15.2 mm	0.6 in	IP68, IP69K, NEMA 6
Sealcon CD09AR-BK	Black	7.87 mm	0.31 in	0.24 in	6.1 mm	100 °C	-40 °C	Polyamide (PA66), Nylon 6/6	0.08 in	2.03 mm	PG9	Cable Gland	15.2 mm	0.6 in	IP68, IP69K, NEMA 6

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	8	$ 1.37

General part information

Cable Gland Polyamide (PA66), Nylon 6/6 PG9 Gray
