3M 4496W CIRCLE-0.813"-1000

Active

3M (TC)

TAPE DBL SIDED WHITE 13/16" DIA

3M 4496W CIRCLE-0.813"-1000

Active

3M (TC)

TAPE DBL SIDED WHITE 13/16" DIA

Description Specifications Series Pricing CAD Documents

Description

General part information

4496W Series

Double Coated, Double Sided Tape Acrylic, 430 Adhesive White 0.81" (20.65mm) 13/16" dia X

Technical Specifications

Parameters and characteristics for this part

Specification	3M 4496W CIRCLE-0.813"-1000

Adhesive	Acrylic
Adhesive (Value)	430
Backing	Polyethylene Foam
Carrier	Polyethylene Foam
Color	White
Shelf Life	18 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Tape Type	Double Sided, Double Coated
Temperature Range (Max)	158 °F
Thickness	0.0625 in
Width	0.81 in

4496W Series

...

Part	Storage/Refrigeration Temperature	Shelf Life	Shelf Life Start	Tape Type	Backing	Carrier	Adhesive (Value)	Adhesive	Usage	Color	Thickness	Length (yd)	Length (ft)	Width	Temperature Range (Max)	Length
3M (TC) 4496W-0.5-5	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic	Holding Joining Mounting	White	0.063 in	5 yd	15 ft	12.7 mm
3M (TC) 0.25-5-4496W	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in	5 yd	15 ft	0.25 in	158 °F
3M (TC) 3M 4496W CIRCLE-0.625"-2000	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in			0.63 in	158 °F
3M (TC) 4496W-2-5	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic	Holding Joining Mounting	White	0.063 in	5 yd	15 ft	2 in
3M (TC) 3M 4496W 8" X 10"-10	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in			8 in	158 °F	10 in
3M (TC) 3M 4496W CIRCLE-0.813"-1000	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in			0.81 in	158 °F
3M (TC) 3M 4496W 10" X 1.25"-5	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in			10 in	158 °F	1.25 in
3M (TC) 8-5-4496W	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in	5 yd	15 ft	8 in	158 °F
3M (TC) 3M 4496W CIRCLE-0.5"-5	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in			12.7 mm	158 °F
3M (TC) 4496WSQ-0.75(250)	70 °F	18 Months	Date of Manufacture	Double Coated Double Sided	Polyethylene Foam	Polyethylene Foam	430	Acrylic		White	0.0625 in			0.75 in	158 °F	0.75 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

No documents available
