9490LE-12-5

Active

3M (TC)

TAPE DBL SIDED CLR 12"X5YDS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

9490LE-12-5

Active

3M (TC)

TAPE DBL SIDED CLR 12"X5YDS

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	9490LE-12-5

Adhesive	Acrylic, 300MP, Acrylic, 300LSE
Backing, Carrier [custom]	Polycoated Kraft
Backing, Carrier [custom]	Polyester
Color	Clear
Length	4.6 m
Length	15 ft
Length	5 yd
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Double Coated, Double Sided
Temperature Range	200 °F
Temperature Range	93 °C
Thickness	0.0067 "
Thickness	0.17 mm
Thickness	6.7 mils
Thickness - Adhesive	0.157 mm
Thickness - Adhesive	6.2 mils
Thickness - Adhesive	0.0062 "
Thickness - Backing, Carrier	0.013 mm
Thickness - Backing, Carrier	0.0005 in
Thickness - Backing, Carrier	0.5 mils
Usage	Holding, Mounting, Joining
Width [x]	304.8 mm
Width [x]	12 in

9490LE Series

...

Part	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Shelf Life	Thickness	Thickness	Thickness	Color	Shelf Life Start	Temperature Range	Temperature Range	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Adhesive	Backing, Carrier [custom]	Backing, Carrier [custom]	Tape Type	Length	Length	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Width	Width	Width	Usage	Length	Width [x]	Width [x]	Length [x]	Length [x]	Width [y]	Width [y]	Width
3M (TC) 3M 9490LE 0.75" X 7"-100	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided	177.8 mm	7 in	0.013 mm	0.0005 in	0.5 mils	0.75 in	19.05 mm	0.75 in
3M (TC) 9490LE-12-5	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided	4.6 m	15 ft	0.013 mm	0.0005 in	0.5 mils				Holding Joining Mounting	5 yd	304.8 mm	12 in
3M (TC) 3M 9490LE 9.25" X 9.25"-25	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided	234.95 mm	9.25 inches	0.013 mm	0.0005 in	0.5 mils						234.95 mm	9.25 in
3M (TC) 9490LE-1-5(100)	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided			0.013 mm	0.0005 in	0.5 mils						25.4 mm	1 in	5 in	127 mm
3M (TC) 9490LE-2-1.25(100)	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided	31.75 mm	1.25 in	0.013 mm	0.0005 in	0.5 mils										2 "	50.8 mm
3M (TC) 3M 9490LE 3" X 5"-50	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided			0.013 mm	0.0005 in	0.5 mils						76.2 mm	3 in	5 in	127 mm
3M (TC) 3M 9490LE CIRCLE-4.000"-100	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided			0.013 mm	0.0005 in	0.5 mils
3M (TC) 9490LE-1.5-60	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided	55 m	180 ft	0.013 mm	0.0005 in	0.5 mils	1.5 "		38.1 mm		60 yds							1 1/2
3M (TC) 3M 9490LE 0.75" X 6"-100	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided	152.4 mm	6 in	0.013 mm	0.0005 in	0.5 mils	0.75 in	19.05 mm	0.75 in
3M (TC) 3M 9490LE 0.5" X 0.75"-250	70 °F	21 °C	24 Months	0.0067 "	0.17 mm	6.7 mils	Clear	Date of Manufacture	93 °C	200 °F	0.157 mm	6.2 mils	0.0062 "	Acrylic 300LSE Acrylic 300MP	Polycoated Kraft	Polyester	Double Coated Double Sided	19.05 mm	0.75 in	0.013 mm	0.0005 in	0.5 mils	0.5 in	0.5 in	12.7 mm		0.75 "

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 83.40

Description

General part information

9490LE Series

Double Coated, Double Sided Tape Acrylic, 300LSE; Acrylic, 300MP Adhesive Clear 12.00" (304.80mm) X 15' (4.6m) 5 yds
