ANR-W-15A-16R

Active

OptiFuse

FUSE AUTO 15A 32VDC BLADE ATO

Search across all available documentation for this part.

Active

OptiFuse

FUSE AUTO 15A 32VDC BLADE ATO

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	ANR-W-15A-16R	ANR-W Series

Breaking Capacity @ Rated Voltage	1 kA	1 kA
Color	Blue	Blue, Red, Yellow
Current Rating (Amps)	15 A	10 - 20 A
Fuse Type	Automotive	Automotive
Mounting Type	Requires Holder	Requires Holder
Package / Case	ATO, Blade, ATC	ATO, Blade, ATC
Response Time	Fast Blow	Fast Blow
Size / Dimension [x]	19.3 mm	19.3 mm
Size / Dimension [x]	0.76 "	0.76 "
Size / Dimension [y]	0.197 "	0.197 "
Size / Dimension [y]	5 mm	5 mm
Size / Dimension [z]	0.494 in	0.494 in
Size / Dimension [z]	12.54 mm	12.54 mm
Voltage Rating - DC	32 V	32 V

FUSE AUTO 15A 32VDC BLADE ATO

Part	Current Rating (Amps)	Color	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Mounting Type	Response Time	Breaking Capacity @ Rated Voltage	Fuse Type	Voltage Rating - DC	Package / Case
OptiFuse ANR-W-15A-16R	15 A	Blue	0.494 in	0.197 "	12.54 mm	19.3 mm	0.76 "	5 mm	Requires Holder	Fast Blow	1 kA	Automotive	32 V	ATC, ATO, Blade
OptiFuse ANR-W-10A-18R	10 A	Red	0.494 in	0.197 "	12.54 mm	19.3 mm	0.76 "	5 mm	Requires Holder	Fast Blow	1 kA	Automotive	32 V	ATC, ATO, Blade
OptiFuse ANR-W-20A-16R	20 A	Yellow	0.494 in	0.197 "	12.54 mm	19.3 mm	0.76 "	5 mm	Requires Holder	Fast Blow	1 kA	Automotive	32 V	ATC, ATO, Blade

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

15 A AC 32 V DC Fuse Automotive Requires Holder Blade, ATO/ATC
