HHBC20-1R7A0152V
ActiveKEMET
CMC 152UH 12A 2LN TH
Deep-Dive with AI
Search across all available documentation for this part.
HHBC20-1R7A0152V
ActiveKEMET
CMC 152UH 12A 2LN TH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | HHBC20-1R7A0152V |
|---|---|
| Current Rating (Max) [Max] | 12 A |
| DC Resistance (DCR) (Max) | 20.4 mOhm |
| Inductance @ Frequency | 152 µH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Vertical, No Base |
| Package / Case | 2 Lead |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 10.29 | |
| 16 | $ 8.06 | |||
| 32 | $ 7.58 | |||
| 64 | $ 7.13 | |||
| 112 | $ 6.79 | |||
| 256 | $ 6.31 | |||
| 512 | $ 5.93 | |||
| 1008 | $ 5.79 | |||
Description
General part information
HHBC20 Series
152 µH @ 100 kHz 2 Line Common Mode Choke Through Hole 12A DCR 20.4mOhm
