FC-5432-12A-C4-C

Obsolete

Delta Electronics/Cyntec

SMD FUSE RATED CURRENT 12A/35VDC

Search across all available documentation for this part.

Obsolete

Delta Electronics/Cyntec

SMD FUSE RATED CURRENT 12A/35VDC

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	FC-5432-12A-C4-C	FC-5432 Series

Applications	Battery Protection	Battery Protection
Approval Agency	TUV, UL	TUV, UL
Breaking Capacity @ Rated Voltage	50 A	50 A
Current Rating (Amps)	12 A	10 - 15 A
Features	-	Triggerable
Features [Max]	19.5 V	14 - 23.5 V
Features [Min]	10.5 V	7 - 14.4 V
Fuse Type	Board Mount	Board Mount
Mounting Type	Surface Mount	Surface Mount
Operating Temperature [Max]	65 °C	65 °C
Operating Temperature [Min]	-10 °C	-10 °C
Package / Case	Nonstandard SMD	Nonstandard SMD
Response Time	Fast Blow	Fast Blow
Size / Dimension [x]	5.4 mm	5.4 mm
Size / Dimension [x]	0.213 "	0.213 "
Size / Dimension [y]	3.2 mm	3.2 mm
Size / Dimension [y]	0.126 "	0.126 "
Size / Dimension [z]	1.15 mm	1.15 mm
Size / Dimension [z]	0.045 "	0.045 "
Voltage Rating - DC	35 V	35 V

SMD FUSE RATED CURRENT 12A/35VDC

Part	Package / Case	Features [Min]	Features [Max]	Features	Approval Agency	Response Time	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage Rating - DC	Applications	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Fuse Type	Breaking Capacity @ Rated Voltage	Current Rating (Amps)
Delta Electronics/Cyntec FC-5432-12A-C3-C	Nonstandard SMD	7 V	14 V	Triggerable	TUV, UL	Fast Blow	5.4 mm	1.15 mm	3.2 mm	0.213 "	0.126 "	0.045 "	35 V	Battery Protection	Surface Mount	-10 °C	65 °C	Board Mount	50 A	12 A
Delta Electronics/Cyntec FC-5432-12A-C4-C	Nonstandard SMD	10.5 V	19.5 V		TUV, UL	Fast Blow	5.4 mm	1.15 mm	3.2 mm	0.213 "	0.126 "	0.045 "	35 V	Battery Protection	Surface Mount	-10 °C	65 °C	Board Mount	50 A	12 A
Delta Electronics/Cyntec FC-5432-10A-C2-C	Nonstandard SMD				TUV, UL	Fast Blow	5.4 mm	1.15 mm	3.2 mm	0.213 "	0.126 "	0.045 "	35 V		Surface Mount	-10 °C	65 °C	Board Mount	50 A	10 A
Delta Electronics/Cyntec FC-5432-15A-C3-C	Nonstandard SMD	7 V	14 V	Triggerable	TUV, UL	Fast Blow	5.4 mm	1.15 mm	3.2 mm	0.213 "	0.126 "	0.045 "	35 V	Battery Protection	Surface Mount	-10 °C	65 °C	Board Mount	50 A	15 A
Delta Electronics/Cyntec FC-5432-15A-C5-C	Nonstandard SMD	14.4 V	23.5 V	Triggerable	TUV, UL	Fast Blow	5.4 mm	1.15 mm	3.2 mm	0.213 "	0.126 "	0.045 "	35 V	Battery Protection	Surface Mount	-10 °C	65 °C	Board Mount	50 A	15 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

12A 35 VDC Fuse Board Mount Surface Mount
