CAN-2054C

Active

ICP DAS USA INC

I/O MOD 8 DIG 8 DIG 10-30V

Search across all available documentation for this part.

Active

ICP DAS USA INC

I/O MOD 8 DIG 8 DIG 10-30V

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CAN-2054C	CAN-2054 Series

Approval Agency	CE	CE
Mounting Type	DIN Rail	DIN Rail
Number of Inputs and Type [custom]	8	8
Number of Inputs and Type [custom]	Digital	Digital
Number of Outputs and Type	8	8
Number of Outputs and Type	Digital	Digital
Operating Temperature [Max]	75 ░C	75 ░C
Operating Temperature [Min]	-25 °C	-25 °C
Termination Style	Screw Terminal	Screw Terminal
Type	Input, Output (I/O) Module	Input, Output (I/O) Module
Voltage - Supply [Max]	30 VDC	30 VDC
Voltage - Supply [Min]	10 VDC	10 VDC

DEVICENET DAQ I/O, 8-CH DI/DO

Part	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Approval Agency	Termination Style	Number of Outputs and Type	Number of Outputs and Type	Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Number of Inputs and Type [custom]	Number of Inputs and Type [custom]
ICP DAS USA INC CAN-2054D	-25 °C	75 ░C	DIN Rail	CE	Screw Terminal	8	Digital	Input, Output (I/O) Module	30 VDC	10 VDC	8	Digital
ICP DAS USA INC CAN-2054C	-25 °C	75 ░C	DIN Rail	CE	Screw Terminal	8	Digital	Input, Output (I/O) Module	30 VDC	10 VDC	8	Digital

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 319.00

General part information

Input, Output (I/O) Module DIN Rail 10 ~ 30VDC
