10110818-2010LF

Unknown

Amphenol ICC (FCI)

CABLE ASSY SFP+ M-M 1M

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

10110818-2010LF

Unknown

Amphenol ICC (FCI)

CABLE ASSY SFP+ M-M 1M

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	10110818-2010LF

Cable Connectors	SFP+
Cable Type	Round
Color	Black
Connector Type	Plug to Plug
Fastening Type	Push-Pull, Latch Lock
Features	Pull Tab, Passive
Frequency - Max [Max]	10 Gbps
Gender	Male to Male
Length [x]	1 m
Length [x]	3.28 ft
Number of Positions	20
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-20 C
Shielding	Unshielded
Usage	External
Wire Gauge	30 AWG

10110818 Series

Part	Wire Gauge	Length [x]	Length [x]	Connector Type	Operating Temperature [Max]	Operating Temperature [Min]	Frequency - Max [Max]	Color	Cable Connectors	Cable Type	Fastening Type	Number of Positions	Gender	Usage	Shielding	Features	Length	Length
Amphenol ICC (FCI) 10110818-4035HFLF	26 AWG	11.48 '	3.5 m	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded
Amphenol ICC (FCI) 10110818-3005LF	28 AWG	1.64 ft	500 mm	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded
Amphenol ICC (FCI) 10110818-3025HFLF	28 AWG	8.2 '	2.5 m	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded
Amphenol ICC (FCI) 10110818-2010LF	30 AWG	3.28 ft	1 m	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded	Passive Pull Tab
Amphenol ICC (FCI) 10110818-5070LF	24 AWG	22.97 '	7 m	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded
Amphenol ICC (FCI) 10110818-3030LF	28 AWG	9.84 ft	3 m	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded
Amphenol ICC (FCI) 10110818-5005LF	24 AWG	1.64 ft	500 mm	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded
Amphenol ICC (FCI) 10110818-5100LF	24 AWG			Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded		10 m	32.81 ft
Amphenol ICC (FCI) 10110818-4020HFLF	26 AWG	6.56 ft	2 m	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded
Amphenol ICC (FCI) 10110818-3040LF	28 AWG	13.12 ft	4 m	Plug to Plug	85 °C	-20 C	10 Gbps	Black	SFP+	Round	Latch Lock Push-Pull	20	Male to Male	External	Unshielded

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	20	$ 19.78

Description

General part information

10110818 Series

20 Position SFP+ Plug to Plug 3.28' (1.00m) Black Unshielded
