Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 14-810.002 | 14 Series |
|---|---|---|
| Driver Circuitry | - | Internally Driven, Indicator |
| Height - Seated (Max) | - | 49 mm |
| Height - Seated (Max) | - | 1.929 in |
| Ingress Protection | - | IP65 - Dust Tight, Water Resistant |
| Input Type | - | DC |
| Mounting Type | - | Through Hole |
| null | - | |
| Port Location | - | Top |
| Size / Dimension | - | 1.142 in |
| Size / Dimension | - | 29 mm |
| Termination | - | Solder Tabs |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
14 Series
Industrial Panel Mount Indicators / Switch Indicators LPB MOM RND W-CLEAR MSHRM LENS
| Part | Termination | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Ingress Protection | Size / Dimension [diameter] | Size / Dimension [diameter] | Input Type | Port Location | Driver Circuitry | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|
EAO 14-551.0250 | ||||||||||
EAO 14-810.002 | Solder Tabs | 49 mm | 1.929 in | IP65 - Dust Tight, Water Resistant | 1.142 in | 29 mm | DC | Top | Indicator, Internally Driven | Through Hole |
EAO 14-810.002 |
Description
General part information
14 Series
Industrial Panel Mount Indicators / Switch Indicators LPB MOM RND W-CLEAR MSHRM LENS
