XEGAGR-H0-0000-000-000000U2001

Active

Cree LED

XLAMP XEG GREEN LED

Search across all available documentation for this part.

Active

Cree LED

XLAMP XEG GREEN LED

Technical Specifications

Parameters and characteristics for this part

Specification	XEGAGR-H0-0000-000-000000U2001

Color	Green
Current - Max [Max]	3 A
Current - Test	1 A
Height - Seated (Max) [Max] [z]	1.13 mm
Height - Seated (Max) [Max] [z]	0.044 "
Luminous Flux @ Current/Temperature	300 lm
Mounting Type	Surface Mount
Package / Case	3-SMD, No Lead
Size / Dimension [x]	2.05 mm
Size / Dimension [x]	0.081 in
Size / Dimension [y]	1.6 mm
Size / Dimension [y]	0.063 in
Supplier Device Package	3-SMD
Viewing Angle	125 °
Voltage - Forward (Vf) (Typ)	3.05 V
Wavelength	530 nm

Part	Current - Test	Luminous Flux @ Current/Temperature	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Voltage - Forward (Vf) (Typ)	Package / Case	Viewing Angle	Color	Wavelength	Mounting Type	Supplier Device Package	Current - Max [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]
Cree LED XEGAGR-H0-0000-000-000000U2001	1 A	300 lm	1.13 mm	0.044 "	3.05 V	3-SMD No Lead	125 °	Green	530 nm	Surface Mount	3-SMD	3 A	2.05 mm	1.6 mm	0.081 in	0.063 in
Cree LED XEGAGR-H0-0000-000-000000U3001	1 A	320 lm	1.13 mm	0.044 "	3.05 V	3-SMD No Lead	125 °	Green	530 nm	Surface Mount	3-SMD	3 A	2.05 mm	1.6 mm	0.081 in	0.063 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	3000	$ 1.33

General part information

LED Lighting Color XLamp® XE-G Green 530nm 3-SMD, No Lead
