MAX11154ETC+
ActiveAnalog Devices Inc./Maxim Integrated
IC ADC 18BIT SAR 12TDFN
Deep-Dive with AI
Search across all available documentation for this part.
MAX11154ETC+
ActiveAnalog Devices Inc./Maxim Integrated
IC ADC 18BIT SAR 12TDFN
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11154ETC+ | MAX11154 Series |
|---|---|---|
| Architecture | SAR | SAR |
| Configuration | S/H-ADC | S/H-ADC |
| Data Interface | DSP, SPI | DSP, SPI |
| Input Type | Pseudo-Differential | Pseudo-Differential |
| Mounting Type | Surface Mount | Surface Mount |
| Number of A/D Converters | 1 | 1 |
| Number of Inputs | 1 | 1 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 12-WFDFN Exposed Pad | 12-WFDFN Exposed Pad |
| Ratio - S/H:ADC | 1:1 | 1:1 |
| Reference Type | External, Internal | External, Internal |
| Sampling Rate (Per Second) | 500k | 500k |
| Supplier Device Package | 12-TDFN (3x3) | 12-TDFN (3x3) |
| Voltage - Supply, Analog | 5 V | 5 V |
| Voltage - Supply, Digital | 5 V | 5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 25.60 | |
| 10 | $ 18.91 | |||
| 25 | $ 17.20 | |||
| 80 | $ 15.55 | |||
| 230 | $ 14.44 | |||
MAX11154 Series
IC ADC 18BIT SAR 12TDFN
| Part | Supplier Device Package | Reference Type | Input Type | Data Interface | Number of Inputs | Configuration | Number of A/D Converters | Voltage - Supply, Digital | Ratio - S/H:ADC | Sampling Rate (Per Second) | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Architecture | Voltage - Supply, Analog | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11154ETC+T | 12-TDFN (3x3) | External, Internal | Pseudo-Differential | DSP, SPI | 1 | S/H-ADC | 1 | 5 V | 1:1 | 500k | 85 °C | -40 °C | 12-WFDFN Exposed Pad | SAR | 5 V | Surface Mount |
Analog Devices Inc./Maxim Integrated MAX11154ETC+ | 12-TDFN (3x3) | External, Internal | Pseudo-Differential | DSP, SPI | 1 | S/H-ADC | 1 | 5 V | 1:1 | 500k | 85 °C | -40 °C | 12-WFDFN Exposed Pad | SAR | 5 V | Surface Mount |
Description
General part information
MAX11154 Series
18 Bit Analog to Digital Converter 1 Input 1 SAR 12-TDFN (3x3)
Documents
Technical documentation and resources
No documents available
