C331C822KAG5TA

Active

KEMET

CAP CER RAD 8.2NF 250V C0G 10%

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

C331C822KAG5TA

Active

KEMET

CAP CER RAD 8.2NF 250V C0G 10%

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	C331C822KAG5TA

Applications	General Purpose
Features	Low ESL
Height - Seated (Max) [Max] [z]	0.36 "
Height - Seated (Max) [Max] [z]	9.14 mm
Lead Spacing	6.35 mm
Lead Spacing	0.25 in
Lead Style	Formed Leads
Mounting Type	Through Hole
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	Radial
Size / Dimension [x]	0.28 in
Size / Dimension [x]	7.11 mm
Size / Dimension [y]	4.07 mm
Size / Dimension [y]	0.16 in
Temperature Coefficient	NP0, C0G
Tolerance	10 %
Voltage - Rated	250 V

C331C Series

...

Part	Lead Style	Voltage - Rated	Mounting Type	Tolerance	Temperature Coefficient	Features	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Package / Case	Capacitance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Applications	Lead Spacing	Lead Spacing	Operating Temperature [Min]	Operating Temperature [Max]
KEMET C331C182FAG5TA	Formed Leads	250 V	Through Hole	1 %	C0G NP0	Low ESL	0.36 "	9.14 mm	Radial	1800 pF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C823G1G5TA	Formed Leads	100 V	Through Hole	2 %	C0G NP0	Low ESL	0.36 "	9.14 mm	Radial	0.082 µF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C393F5G5TA	Formed Leads	50 VDC	Through Hole	1 %	C0G NP0	Low ESL	0.36 "	9.14 mm	Radial	0.039 µF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C274J5G5TA	Straight	50 VDC	Through Hole	5 %	C0G NP0	Low ESL	0.42 in	10.66 mm	Radial	0.27 µF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C123FAG5TA	Formed Leads	250 V	Through Hole	1 %	C0G NP0	Low ESL	0.36 "	9.14 mm	Radial	0.012 µF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C184K5G5TA	Straight	50 VDC	Through Hole	10 %	C0G NP0	Low ESL	0.42 in	10.66 mm	Radial	0.18 µF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C822KAG5TA	Formed Leads	250 V	Through Hole	10 %	C0G NP0	Low ESL	0.36 "	9.14 mm	Radial		4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C104KAG5TA	Straight	250 V	Through Hole	10 %	C0G NP0	Low ESL	0.36 "	9.14 mm	Radial	100000 pF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C393K5G5TA	Formed Leads	50 VDC	Through Hole	10 %	C0G NP0	Low ESL	0.36 "	9.14 mm	Radial	0.039 µF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C
KEMET C331C124G1G5TA	Straight	100 V	Through Hole	2 %	C0G NP0	Low ESL	0.42 in	10.66 mm	Radial	0.12 µF	4.07 mm	0.16 in	0.28 in	7.11 mm	General Purpose	6.35 mm	0.25 in	-55 °C	125 °C

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1000	$ 0.21

Description

General part information

C331C Series

8200 pF ±10% 250V Ceramic Capacitor C0G, NP0 Radial
