811-22-010-30-001101

Active

Mill-Max Manufacturing Corp.

CONN SPRING PISTON 10POS SMD

Search across all available documentation for this part.

Active

Mill-Max Manufacturing Corp.

CONN SPRING PISTON 10POS SMD

Technical Specifications

Parameters and characteristics for this part

...

Part	Contact Finish Thickness	Contact Finish Thickness	Mounting Type	Material	Number of Rows	Number of Contacts	Pitch [x]	Pitch [x]	Contact Finish	Connector Type
Mill-Max Manufacturing Corp. 811-22-060-30-000101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	60	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-007-30-001101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	7	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-042-30-002101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	42	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-010-30-001101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	10	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-024-30-002101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	24	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-009-30-001101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	9	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-055-30-001101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	55 contacts	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-027-30-002101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	27	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-056-30-002101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	56	2.54 mm	0.1 in	Gold	Piston
Mill-Max Manufacturing Corp. 811-22-007-30-004101	0.51 µm	20 µin	Surface Mount	Copper Alloy	1	7	2.54 mm	0.1 in	Gold	Piston

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Position Spring Piston Connector Surface Mount

Technical documentation and resources

No documents available
