Cable Assemblies
A9CAG-0505F
ActiveTE Connectivity Raychem Cable Protection
FLEX CABLE - AFG05G/AF05/AFE05T
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | A9CAG-0505F |
|---|---|
| Length [x] | 5 in |
| Length [x] | 127 mm |
| Pitch [x] | 2.54 mm |
| Pitch [x] | 0.1 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 6.40 | |
| 10 | $ 5.31 | |||
| 25 | $ 4.92 | |||
| 50 | $ 4.65 | |||
| 100 | $ 4.40 | |||
| 250 | $ 4.08 | |||
| 500 | $ 3.86 | |||
| 1000 | $ 3.65 | |||
| 2500 | $ 3.41 | |||
Description
General part information
A9CAG Series
5 Position Flat Flex Cable Assembly Receptacle with Latch to Solder Tab 5.00" (127.00mm)
