Specification	690-004-621-013

Connector Type	USB-A (USB TYPE-A)
Contact Finish	Gold
Features	Board Lock
Gender	Receptacle
Insulation Color	Black
Material Flammability Rating	UL94 V-0
Mating Cycles	1500 cycles
Mounting Feature	Horizontal
Mounting Type	Through Hole, Right Angle
Number of Contacts	4
Number of Ports	1
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-55 °C
Shell/Shielding Material	Copper Alloy
Shielding	Unshielded
Specifications	USB 2.0
Termination	Solder

690-004 Series

Part	Shielding	Number of Contacts	Connector Type	Gender	Features	Mating Cycles	Mounting Type	Specifications	Mounting Feature	Number of Ports	Termination	Operating Temperature (Min)	Operating Temperature (Max)	Contact Finish	Insulation Color	Material Flammability Rating	Shell/Shielding Material
EDAC Inc. 690-004-621-013	Unshielded	4	USB-A (USB TYPE-A)	Receptacle	Board Lock	1500 cycles	Right Angle Through Hole	USB 2.0	Horizontal	1	Solder	-55 °C	85 °C	Gold	Black	UL94 V-0	Copper Alloy
EDAC Inc. 690-004-321-013	Unshielded	4	USB-A (USB TYPE-A)	Receptacle	Board Lock	1500 cycles	Right Angle Through Hole	USB 2.0	Horizontal	1	Solder	-55 °C	85 °C	Gold	Black	UL94 V-0	Copper Alloy
EDAC Inc. 690-004-661-906		4		Receptacle							Solder
