STEVAL-ILL002V3

Obsolete

STMicroelectronics

EVAL BOARD FOR STP08DP05

Search across all available documentation for this part.

Obsolete

STMicroelectronics

EVAL BOARD FOR STP08DP05

Technical Specifications

Parameters and characteristics for this part

Part	Number of Outputs	Type	Topology	Supplier Device Package	Mounting Type	Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output	Current - Output / Channel	Package / Case	Package / Case [x]	Package / Case [y]	Voltage - Supply (Min) [Min]	Voltage - Supply (Max)	Package / Case	Package / Case	Outputs and Type	Voltage - Input [Min]	Voltage - Input [Max]	Supplied Contents	Utilized IC / Part
STMicroelectronics STP08DP05MTR	8	Linear	Shift Register	16-SO	Surface Mount	30 MHz	-40 °C	125 °C	20 V	100 mA	16-SOIC	0.154 in	3.9 mm	3 V	5.5 V
STMicroelectronics STP08DP05B1	8	Linear	Shift Register	16-DIP	Through Hole	30 MHz	-40 °C	125 °C	20 V	100 mA	16-DIP			3 V	5.5 V	0.3 in	7.62 mm
STMicroelectronics STP08DP05TTR	8	Linear	Shift Register	16-TSSOP	Surface Mount	30 MHz	-40 °C	125 °C	20 V	100 mA	16-TSSOP	0.173 in	4.4 mm	3 V	5.5 V
STMicroelectronics STEVAL-ILL002V3									20 V	100 mA								8 Non-Isolated Outputs	7 V	32 V	Board(s)	STP08DP05

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

STP08DP05 - 8 Non-Isolated Outputs pval(5) LED Driver Evaluation Board
