ME-XU1-15EG-2I-D12E-R4.1

Obsolete

Enclustra FPGA Solutions

SOM ZYNQ US+ ZU15EG 4GB

Search across all available documentation for this part.

Obsolete

Enclustra FPGA Solutions

SOM ZYNQ US+ ZU15EG 4GB

Technical Specifications

Parameters and characteristics for this part

Specification	ME-XU1-15EG-2I-D12E-R4.1

Connector Type	168 Pin
Core Processor	ARM® Dual-Core Cortex-R5, Mali-400MP2 GPU, ARM® Dual-/Quad-Core Cortex-A53
Flash Size	16 GB
Module/Board Type	FPGA Core, MPU
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
RAM Size	4 GB
Size / Dimension [x]	2.91 "
Size / Dimension [x]	74 mm
Size / Dimension [y]	54 mm
Size / Dimension [y]	2.13 in
Speed	1.5 GHz
Speed	600 MHz

SOM ZYNQ US+ ZU15EG 4GB

Part	Connector Type	RAM Size	Speed	Speed	Operating Temperature [Max]	Operating Temperature [Min]	Flash Size	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Module/Board Type	Core Processor
Enclustra FPGA Solutions ME-XU1-15EG-2I-D12E-R4.1	168 Pin	4 GB	1.5 GHz	600 MHz	85 °C	-40 °C	16 GB	54 mm	2.91 "	74 mm	2.13 in	FPGA Core, MPU	ARM® Dual-/Quad-Core Cortex-A53, ARM® Dual-Core Cortex-R5, Mali-400MP2 GPU

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

- Embedded Module ARM® Dual-/Quad-Core Cortex-A53, ARM® Dual-Core Cortex-R5, Mali-400MP2 GPU 600MHz, 1.5GHz 4GB 16GB
