8460 063U1000

Active

Belden Inc.

TW PR BLK & NAT

Search across all available documentation for this part.

Active

Belden Inc.

TW PR BLK & NAT

Technical Specifications

Parameters and characteristics for this part

Specification	8460 063U1000

Cable Type	Speaker
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Jacket (Insulation) Diameter [diameter]	4.57 mm
Jacket (Insulation) Diameter [diameter]	0.18 in
Jacket Color	White, Black
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-30 ░C
Usage	Audio
Voltage	300 V
Wire Gauge	18 AWG

Part	Conductor Insulation	Conductor Material	Jacket Color	Voltage	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Usage	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length
Belden Inc. 8460 0635000	Poly-Vinyl Chloride (PVC)	Copper Tinned	Black White	300 V	18 AWG	-30 ░C	80 C	Speaker	4.57 mm	0.18 in	2	Audio	26 AWG	7
Belden Inc. 8460 063U1000	Poly-Vinyl Chloride (PVC)	Copper Tinned	Black White	300 V	18 AWG	-30 ░C	80 C	Speaker	4.57 mm	0.18 in	2	Audio	26 AWG	7	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 0.98

General part information

2 Conductor Speaker Cable Black, White 18 AWG 1000.0' (304.8m)
