GCHDLP62M62F

Active

MH Connectors

D SUB CONNECTOR ADAPTER, HIGH DENSITY D SUB, PLUG, 62 POSITIONS, HIGH DENSITY D SUB, RECEPTACLE

Search across all available documentation for this part.

Active

MH Connectors

D SUB CONNECTOR ADAPTER, HIGH DENSITY D SUB, PLUG, 62 POSITIONS, HIGH DENSITY D SUB, RECEPTACLE

Technical Specifications

Parameters and characteristics for this part

Specification	GCHDLP62M62F

Connector Style	Connector Saver
Contact Finish	Gold
Contact Finish Thickness	Flash
Convert From (Adapter End)	D-Sub, Male, 62 HD
Convert To (Adapter End)	D-Sub, Female, 62 HD
Current Rating (Amps)	3 A
Housing Color	Yellow
Includes	1 Connector, 2 Jack Screws
Material Flammability Rating	UL94 V-0
Number of Rows	3
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C

Part	Includes	Contact Finish	Convert To (Adapter End)	Housing Color	Number of Rows	Current Rating (Amps)	Convert From (Adapter End)	Operating Temperature [Max]	Operating Temperature [Min]	Material Flammability Rating	Connector Style	Contact Finish Thickness
MH Connectors GCHDLP62F62F	1 Connector 2 Jack Screws 2 Nuts	Gold	62 HD D-Sub Female	Yellow	3	3 A	62 HD D-Sub Female	105 ░C	-55 °C	UL94 V-0	Gender Changer	Flash
MH Connectors GCHDLP62M62F	1 Connector 2 Jack Screws	Gold	62 HD D-Sub Female	Yellow	3	3 A	62 HD D-Sub Male	105 ░C	-55 °C	UL94 V-0	Connector Saver	Flash

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Adapter Connector D-Sub, 62 HD, Female To D-Sub, 62 HD, Male Panel Mount
