C8RRS-1618M
ActiveCW Industries
DIP CABLE - CDR16S/AE16M/CDR16S
Deep-Dive with AI
DocumentsRibbon Cable Assembly Length Guide
Technical Specifications
Parameters and characteristics for this part
| Specification | C8RRS-1618M |
|---|---|
| Cable Termination | IDC |
| Color | Ribbon, Multiple |
| Connector Type | DIP to DIP, Reversed |
| Contact Finish | Tin |
| Contact Finish Thickness | 2.54 µm |
| Contact Finish Thickness | 100 µin |
| Features | Strain Relief |
| Length [x] | 457.2 mm |
| Length [x] | 1.5 ft |
| Number of Positions | 16 |
| Number of Rows | 2 |
| Pitch - Cable | 0.05 " |
| Pitch - Cable | 1.27 mm |
| Pitch - Connector | 0.1 in |
| Pitch - Connector | 2.54 mm |
| Shielding | Unshielded |
| Usage | Socket (0.3"), Board In |
C8RRS-1 Series
| Part | Contact Finish Thickness | Contact Finish Thickness | Usage | Number of Positions | Connector Type | Contact Finish | Length | Length | Length | Cable Termination | Features | Pitch - Connector | Pitch - Connector | Pitch - Cable | Pitch - Cable | Number of Rows | Shielding | Number of Positions | Color | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CW Industries | 2.54 µm | 100 µin | Board In Socket (0.3") | 16 | DIP to DIP Reversed | Tin | 152.4 mm | 6 " | 0.5 ' | IDC | Strain Relief | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | 2 | Unshielded | ||||
CW Industries | 2.54 µm | 100 µin | Board In Socket (0.3") | DIP to DIP Reversed | Tin | IDC | Strain Relief | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | 2 | Unshielded | 14 | Multiple Ribbon | 3 ft | 914.4 mm | ||||
CW Industries | 2.54 µm | 100 µin | Board In Socket (0.3") | DIP to DIP Reversed | Tin | IDC | Strain Relief | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | 2 | Unshielded | 14 | 1.5 ft | 457.2 mm | |||||
CW Industries | 2.54 µm | 100 µin | Board In Socket (0.3") | DIP to DIP Reversed | Tin | IDC | Strain Relief | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | 2 | Unshielded | 14 | Multiple Ribbon | 1.5 ft | 457.2 mm | ||||
CW Industries | 2.54 µm | 100 µin | Board In Socket (0.3") | DIP to DIP Reversed | Tin | 152.4 mm | 6 " | 0.5 ' | IDC | Strain Relief | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | 2 | Unshielded | 14 | ||||
CW Industries | 2.54 µm | 100 µin | Board In Socket (0.3") | 16 | DIP to DIP Reversed | Tin | IDC | Strain Relief | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | 2 | Unshielded | Multiple Ribbon | 3 ft | 914.4 mm | ||||
CW Industries | 2.54 µm | 100 µin | Board In Socket (0.3") | 16 | DIP to DIP Reversed | Tin | IDC | Strain Relief | 0.1 in | 2.54 mm | 0.05 " | 1.27 mm | 2 | Unshielded | Multiple Ribbon | 1.5 ft | 457.2 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 4.90 | |
| 10 | $ 4.45 | |||
| 25 | $ 4.22 | |||
| 50 | $ 4.12 | |||
| 100 | $ 3.92 | |||
| 250 | $ 3.43 | |||
| 500 | $ 3.33 | |||
| 1000 | $ 2.84 | |||
| 2500 | $ 2.65 | |||
Description
General part information
C8RRS-1 Series
16 Position Cable Assembly Rectangular DIP to DIP, Reversed 1.50' (457.20mm)
