AZSR180-1AE-12D

Active

American Zettler

RELAY EV CHG SOLAR SPST 80A 12V

Search across all available documentation for this part.

Active

American Zettler

RELAY EV CHG SOLAR SPST 80A 12V

Technical Specifications

Parameters and characteristics for this part

RELAY EV CHG SOLAR SPST 80A 12V

Part	Coil Voltage	Mounting Type	Coil Type	Operating Temperature [Max]	Operating Temperature [Min]	Contact Form	Release Time	Contact Rating (Current)	Approval Agency	Contact Material	Must Operate Voltage	Coil Insulation	Coil Resistance	Relay Type	Switching Voltage	Termination Style	Operate Time	Must Release Voltage	Coil Current	Load - Max Switching
American Zettler AZSR180-1AE-12D	12 VDC	Through Hole	Non Latching	85 °C	-40 °C	SPST-NO (1 Form A)	5 ms	80 A	UL, VDE	Silver Tin Oxide (AgSnO)	9 VDC	Class F	300 Ohms	EV Charging, Solar	150 VDC, 440 VAC	PC Pin	40 ms	0.6 VDC	40 mA	2400 W, 22160 VA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

EV Charging, Solar Relay SPST-NO (1 Form A) 12VDC Coil Through Hole
