IPSU-GP100-6M12

Obsolete

Sensata Technologies

PRESSURE SENSOR 0-100PSIG 1/4"NP

Search across all available documentation for this part.

Obsolete

Sensata Technologies

PRESSURE SENSOR 0-100PSIG 1/4"NP

Technical Specifications

Parameters and characteristics for this part

Specification	IPSU-GP100-6M12

Accuracy	0.25 %
Applications	Industrial Automation
Features	Temperature Compensated, Amplified Output
Operating Pressure	689.48 kPa
Operating Pressure	100 PSI
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Output [Max]	5 V
Output [Min]	0 mV
Output Type	Analog Voltage
Package / Case	Cylinder, Threaded - M12
Port Size [custom]	NPT
Port Size [custom]	Male
Port Size [x]	0.25 "
Port Size [x]	6.35 mm
Port Style	Threaded
Pressure Type	Vented Gauge
Termination Style	Connector
Voltage - Supply [Max]	32 VDC
Voltage - Supply [Min]	9 V

Part	Output Type	Pressure Type	Port Size [custom]	Port Size [x]	Port Size [x]	Port Size [custom]	Operating Pressure	Operating Pressure	Features	Termination Style	Applications	Voltage - Supply [Min]	Voltage - Supply [Max]	Package / Case	Output [Max]	Output [Min]	Accuracy	Operating Temperature [Min]	Operating Temperature [Max]	Port Style
Sensata Technologies IPSU-GP100-6M12	Analog Voltage	Vented Gauge	NPT	0.25 "	6.35 mm	Male	689.48 kPa	100 PSI	Amplified Output Temperature Compensated	Connector	Industrial Automation	9 V	32 VDC	Cylinder Threaded - M12	5 V	0 mV	0.25 %	-20 C	80 C	Threaded

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

PRESSURE SENSOR 0-100PSIG 1/4"NP

Technical documentation and resources

No documents available
