MAX11270EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION KIT FOR MAX1127
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX11270EVKIT#
ActiveAnalog Devices Inc./Maxim Integrated
EVALUATION KIT FOR MAX1127
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11270EVKIT# | MAX11270 Series |
|---|---|---|
| Architecture | - | Sigma-Delta |
| Configuration | - | PGA-ADC |
| Data Interface | SPI | SPI |
| Features | - | PGA |
| Input Range | ±VREF | ±VREF |
| Input Type | - | Differential |
| Mounting Type | - | Surface Mount |
| Number of A/D Converters | 1 | 1 |
| Number of Bits | 24 | 24 |
| Number of Inputs | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 24-TSSOP |
| Package / Case | - | 0.173 - 4.4 in |
| Power (Typ) @ Conditions | 10 mW | 10 mW |
| Reference Type | - | External |
| Sampling Rate (Per Second) | 64k | 64k |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 24-TSSOP |
| Utilized IC / Part | MAX11270 | MAX11270 |
| Voltage - Supply, Analog | - | 2.7 V |
| Voltage - Supply, Analog | - | 1.8 V |
| Voltage - Supply, Analog | - | 3.6 V |
| Voltage - Supply, Digital | - | 3.6 V |
| Voltage - Supply, Digital | - | 2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 119.00 | |
MAX11270 Series
EVALUATION KIT FOR MAX1127
| Part | Number of Bits | Power (Typ) @ Conditions | Supplied Contents | Sampling Rate (Per Second) | Utilized IC / Part | Input Range | Data Interface | Number of A/D Converters | Configuration | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply, Analog [Min] | Voltage - Supply, Analog | Voltage - Supply, Analog [Max] | Input Type | Mounting Type | Package / Case | Package / Case | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Reference Type | Number of Inputs | Architecture | Features | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11270EVKIT# | 24 | 10 mW | Board(s) | 64k | MAX11270 | ±VREF | SPI | 1 | |||||||||||||||||
Analog Devices Inc./Maxim Integrated MAX11270EUG+T | 24 | 64k | SPI | 1 | PGA-ADC | 85 °C | -40 °C | 2.7 V | 1.8 V | 3.6 V | Differential | Surface Mount | 24-TSSOP | 0.173 in, 4.4 mm | 3.6 V | 2 V | External | 1 | Sigma-Delta | PGA | 24-TSSOP | ||||
Analog Devices Inc./Maxim Integrated MAX11270EUG+ | 24 | 64k | SPI | 1 | PGA-ADC | 85 °C | -40 °C | 2.7 V | 1.8 V | 3.6 V | Differential | Surface Mount | 24-TSSOP | 0.173 in, 4.4 mm | 3.6 V | 2 V | External | 1 | Sigma-Delta | PGA | 24-TSSOP |
Description
General part information
MAX11270 Series
MAX11270 - 24 Bit 64k Samples per Second Analog to Digital Converter (ADC) Evaluation Board
