ZSD0060A

Active

RED LION CONTROLS

ROTARY ENCODER MECHANICAL 60PPR

Search across all available documentation for this part.

Active

RED LION CONTROLS

ROTARY ENCODER MECHANICAL 60PPR

Technical Specifications

Parameters and characteristics for this part

Specification	ZSD0060A

Actuator Type	0.25
Actuator Type	Flatted End
Detent	False
Encoder Type	Mechanical
Mounting Type	Chassis Mount, Motors
Output Type	Quadrature with Index (Incremental)
Pulses per Revolution	60
Termination Style	Cable
Voltage - Supply [Max]	28 V
Voltage - Supply [Min]	4.75 V

ROTARY ENCODER MECHANICAL 60PPR

Part	Encoder Type	Detent	Output Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Actuator Type	Actuator Type	Mounting Type	Termination Style	Pulses per Revolution
RED LION CONTROLS ZSD0060A	Mechanical		Quadrature with Index (Incremental)	4.75 V	28 V	0.25	Flatted End	Chassis Mount, Motors	Cable	60

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 415.36

General part information

ROTARY ENCODER MECHANICAL 60PPR

Technical documentation and resources

No documents available
