C1AXG-6036M

Active

CW Industries

IDC CABLE - CSC60G/AE60M/X

Search across all available documentation for this part.

Active

CW Industries

IDC CABLE - CSC60G/AE60M/X

Technical Specifications

Parameters and characteristics commom to parts in this series

IDC CABLE - CSC60G/AE60G/X

Part	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Cable Termination	Pitch - Cable	Pitch - Cable	Shielding	Number of Rows	Number of Positions	Connector Type	Length [x]	Length [x]	Pitch - Connector	Pitch - Connector	Color
CW Industries C1AXG-6036G	Gold	10 Áin	0.25 Ám	IDC	0.05 "	1.27 mm	Unshielded	2	60	Socket to Cable	3 ft	914.4 mm	0.1 in	2.54 mm
CW Industries C1AXG-6036M	Gold	10 Áin	0.25 Ám	IDC	0.05 "	1.27 mm	Unshielded	2	60	Socket to Cable	3 ft	914.4 mm	0.1 in	2.54 mm	Multiple, Ribbon

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

60 Position Cable Assembly Rectangular Socket to Cable 3.00' (914.40mm)
