Q-2202D000R084i

Active

Amphenol Custom Cable

COAX CBL N-TYPE TO N-TYPE 7'

Search across all available documentation for this part.

Active

Amphenol Custom Cable

COAX CBL N-TYPE TO N-TYPE 7'

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2202D000R084i

1st Connector	N-Type Jack
1st Connector Mounting Feature	Bulkhead - Front Side Nut
1st Connector Mounting Type	Panel Mount
1st Contact Gender	Female
2nd Connector	N-Type Plug, Right Angle
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Type	RG-316 DB
Color	Copper
Features	Shielded
Frequency - Max [Max]	11 GHz
Length	84 in
Length	2.1 m
Length	7 ft
Overall Impedance	50 Ohms
Style	N-Type to N-Type

Part	Features	1st Contact Gender	Frequency - Max [Max]	Style	Cable Type	1st Connector Mounting Feature	Overall Impedance	2nd Connector Mounting Type	Color	2nd Contact Gender	1st Connector	1st Connector Mounting Type	Length	Length	Length	2nd Connector
Amphenol Custom Cable Q-2202D000R084i	Shielded	Female	11 GHz	N-Type to N-Type	RG-316 DB	Bulkhead - Front Side Nut	50 Ohms	Free Hanging (In-Line)	Copper	Male	N-Type Jack	Panel Mount	84 in	2.1 m	7 ft	N-Type Plug Right Angle

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Assembly Coaxial N-Type to N-Type RG-316 DB 84.0" (2.1m) 7.0'

Technical documentation and resources

No documents available
