C274AA24800AA0J

Active

KEMET

CAP FILM 8UF 5% 470VAC RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 8UF 5% 470VAC RADIAL

Technical Specifications

Parameters and characteristics for this part

Specification	C274AA24800AA0J

Applications	Motor Run
Capacitance	8 µF
Dielectric Material	Metallized, Polypropylene (PP)
Height - Seated (Max) [Max] [z]	58.5 mm
Height - Seated (Max) [Max] [z]	2.303 in
Lead Spacing	0.394 in
Lead Spacing	10 mm
Mounting Type	Chassis, Stud Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-25 °C
Package / Case	Radial, Can
Size / Dimension [diameter]	1.378 in
Size / Dimension [diameter]	35 mm
Termination	0.25 in
Termination	6.3 mm
Termination	Quick Connect
Tolerance	5 %
Voltage Rating - AC	470 V

Part	Termination	Termination	Termination	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Voltage Rating - AC	Tolerance	Size / Dimension [diameter]	Size / Dimension [diameter]	Applications	Package / Case	Dielectric Material	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Capacitance	Lead Spacing	Lead Spacing
KEMET C274AA24500AA0J	0.25 in	6.3 mm	Quick Connect	58.5 mm	2.303 in	470 V	5 %	30 mm	1.181 inches	Motor Run	Radial Can	Metallized Polypropylene (PP)	-25 °C	85 °C	Chassis Stud Mount	5 µF	0.394 in	10 mm
KEMET C274AA24600AA0J	0.25 in	6.3 mm	Quick Connect	58.5 mm	2.303 in	470 V	5 %	35 mm	1.378 in	Motor Run	Radial Can	Metallized Polypropylene (PP)	-25 °C	85 °C	Chassis Stud Mount	6 µF	0.394 in	10 mm
KEMET C274AA24800AA0J	0.25 in	6.3 mm	Quick Connect	58.5 mm	2.303 in	470 V	5 %	35 mm	1.378 in	Motor Run	Radial Can	Metallized Polypropylene (PP)	-25 °C	85 °C	Chassis Stud Mount	8 µF	0.394 in	10 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

8 µF Film Capacitor 470V Polypropylene (PP), Metallized Radial, Can
