34020 0082000

Active

Belden Inc.

HOOK-UP STRND 20AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 20AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	34020 0082000

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	105
Conductor Strand [custom]	40 AWG
Jacket (Insulation) Diameter [diameter]	2.79 mm
Jacket (Insulation) Diameter [diameter]	0.11 in
Jacket (Insulation) Material	Glass, Silicone
Jacket (Insulation) Thickness	0.81 mm
Jacket (Insulation) Thickness	0.032 in
Jacket Color	Gray
Length [x]	609.6 m
Length [x]	2000 ft
Voltage	600 V
Wire Gauge	20 AWG

Part	Voltage	Length [x]	Length [x]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Cable Type	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Wire Gauge
Belden Inc. 34020 0082000	600 V	609.6 m	2000 ft	0.81 mm	0.032 in	Copper Tinned	2.79 mm	0.11 in	Gray	Hook-Up	105	40 AWG	Glass Silicone	20 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	2000	$ 1.66

General part information

20 AWG Hook-Up Wire 105/40 Gray 600V 2000.0' (609.6m)
