7987P 1NDU1000

Active

Belden Inc.

4 PR #24 FEP FLRST

Search across all available documentation for this part.

Active

Belden Inc.

4 PR #24 FEP FLRST

Technical Specifications

Parameters and characteristics for this part

Specification	7987P 1NDU1000

Cable Type	Multi-Pair
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Bare
Conductor Strand	Solid
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	5.11 mm
Jacket (Insulation) Diameter [diameter]	0.201 in
Jacket (Insulation) Material	Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum
Jacket Color	Maroon
Length	1000 ft
Length	304.8 m
Number of Conductors	8
Ratings	UL Style CMP
Usage	Video
Voltage	300 V
Wire Gauge	24 AWG

Part	Conductor Material	Jacket (Insulation) Material	Jacket Color	Length	Length	Wire Gauge	Ratings	Features	Number of Conductors	Cable Type	Conductor Insulation	Usage	Voltage	Conductor Strand	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]
Belden Inc. 7987P 1NDU1000	Copper Bare	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	Maroon	1000 ft	304.8 m	24 AWG	UL Style CMP	Rip Cord	8	Multi-Pair	Fluorinated Ethylene-Propylene (FEP)	Video	300 V	Solid	5.11 mm	0.201 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 1.20

General part information

8 (4 Pair Twisted) Conductor Multi-Pair Cable Maroon 24 AWG 1000.0' (304.8m)

Technical documentation and resources
