ASB02512VHA-A76N
ActiveDelta Electronics
FAN AXIAL 25X10MM 12VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ASB02512VHA-A76N
ActiveDelta Electronics
FAN AXIAL 25X10MM 12VDC WIRE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ASB02512VHA-A76N |
|---|---|
| Air Flow | 0.095 m³/min |
| Air Flow | 3.4 CFM |
| Approval Agency | cURus, TUV |
| Bearing Type | Sleeve |
| Current Rating (Amps) | 50 mA |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Sensor |
| Lifetime @ Temp. | 30000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Noise | 27 dB(A) |
| Operating Temperature [Max] | 75 °C |
| Operating Temperature [Max] | 75 ░C |
| Operating Temperature [Min] | -10 °C |
| Operating Temperature [Min] | -10 °C |
| Power (Watts) | 600 mW |
| RPM | 13000 RPM |
| Size / Dimension [x] | 25 mm |
| Size / Dimension [z] | 25 mm |
| Static Pressure | 53.3 Pa |
| Static Pressure | 0.214 in H2O |
| Termination | 3 Wire Leads |
| Voltage - Rated | 12 VDC |
| Voltage Range [Max] | 13.8 VDC |
| Voltage Range [Min] | 4.75 VDC |
| Weight | 0.014 lb |
| Weight | 6.35 g |
| Width [y] | 10 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 5.40 | |
| 10 | $ 4.95 | |||
| 25 | $ 4.50 | |||
| 50 | $ 4.16 | |||
| 100 | $ 3.96 | |||
Description
General part information
ASB02512 Series
Fan Tubeaxial 12VDC Square - 25mm L x 25mm H Sleeve 3.4 CFM (0.095m³/min) 3 Wire Leads
