6609973-4

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 6A CHASSIS MOUNT

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 6A CHASSIS MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	6609973-4

Applications	General Purpose
Configuration	Single Stage
Current	6 A
Filter Type	Single Phase
Frequency - Operating [Max]	60 Hz
Frequency - Operating [Min]	50 Hz
Mounting Type	Chassis Mount
Operating Temperature [Max]	40 °C
Operating Temperature [Min]	-10 °C
Termination Style	Quick Connect
Voltage - Rated AC (Phase to Ground/Neutral)	480 V
Voltage - Rated AC (Phase to Phase)	500 V

Part	Frequency - Operating [Max]	Frequency - Operating [Min]	Termination Style	Filter Type	Voltage - Rated AC (Phase to Phase)	Applications	Mounting Type	Current	Operating Temperature [Min]	Operating Temperature [Max]	Configuration	Voltage - Rated AC (Phase to Ground/Neutral)
TE Connectivity Raychem Cable Protection 6609973-1	60 Hz	50 Hz	Terminal Block	Single Phase	500 V	General Purpose	Chassis Mount	16 A	-10 °C	40 °C	Single Stage	480 V
TE Connectivity Raychem Cable Protection 6609973-4	60 Hz	50 Hz	Quick Connect	Single Phase	500 V	General Purpose	Chassis Mount	6 A	-10 °C	40 °C	Single Stage	480 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	32	$ 81.64

General part information

Single Phase EMC/EMI Line Filter 6 A 50/60Hz Single Stage Quick Connect
