HA15-0.9-A+G

Active

SL POWER / Advanced Energy

AC/DC POWER SUPPLY SINGLE-OUT 15V 0.9A 288W CASE B

Search across all available documentation for this part.

Active

SL POWER / Advanced Energy

AC/DC POWER SUPPLY SINGLE-OUT 15V 0.9A 288W CASE B

Technical Specifications

Parameters and characteristics for this part

Specification	HA15-0.9-A+G

Applications	ITE (Commercial)
Approval Agency	cURus, CE, TUV
Current - Output 1	900 mA
Efficiency	55 %
Features	Remote Sense, Universal Input, Adjustable Output
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Size / Dimension [x]	124 mm
Size / Dimension [x]	4.88 "
Size / Dimension [y]	4 "
Size / Dimension [y]	101.6 mm
Size / Dimension [z]	45.7 mm
Size / Dimension [z]	1.8 "
Type	Linear
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	100 VAC
Voltage - Output 1	15 V

AC/DC POWER SUPPLY SINGLE-OUT 15V 0.9A 288W CASE B

Part	Approval Agency	Voltage - Input [Max]	Voltage - Input [Min]	Efficiency	Voltage - Output 1	Applications	Features	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Number of Outputs	Current - Output 1	Type	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type
SL POWER / Advanced Energy HA15-0.9-A+G	CE, cURus, TUV	264 VAC	100 VAC	55 %	15 V	ITE (Commercial)	Adjustable Output, Remote Sense, Universal Input	4 "	124 mm	45.7 mm	4.88 "	1.8 "	101.6 mm	1	900 mA	Linear	70 °C	0 °C	Chassis Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Linear AC DC Converters 1 Output 15V 100 ~ 264 VAC Input
