PV3WF2B0SS-335

Active

E-Switch

SWITCH PUSHBUTTON SPDT 2A 48V

Search across all available documentation for this part.

Active

E-Switch

SWITCH PUSHBUTTON SPDT 2A 48V

Technical Specifications

Parameters and characteristics for this part

Specification	PV3WF2B0SS-335

Actuator Marking	No Marking
Actuator Type	Flush, Button, Round
Circuit	SPDT
Color - Actuator/Cap	Silver
Current Rating (Amps)	2 A
Electrical Life	50000 Cycles
Illumination Type, Color	LED, Green
Illumination Voltage (Nominal)	24 V
Ingress Protection	IP67 - Dust Tight, Waterproof
Mechanical Life	200000 Cycles
Mounting Type	Panel Mount, Front
Operating Temperature [Max]	55 °C
Operating Temperature [Min]	-20 C
Panel Cutout Dimensions [diameter]	16 mm
Switch Function	On-Mom
Termination Style	Solder Lug
Type	Anti-Vandal, Illuminated
Voltage Rating - DC	48 V

Part	Actuator Marking	Mechanical Life	Illumination Voltage (Nominal)	Mounting Type	Actuator Type	Ingress Protection	Panel Cutout Dimensions [diameter]	Circuit	Voltage Rating - DC	Type	Color - Actuator/Cap	Termination Style	Electrical Life	Switch Function	Operating Temperature [Max]	Operating Temperature [Min]	Illumination Type, Color	Current Rating (Amps)
E-Switch PV3WF2B011-333	No Marking	200000 Cycles	6 V	Panel Mount Front	Button Flush Round	IP67 - Dust Tight Waterproof	16 mm	SPDT	48 V	Anti-Vandal Illuminated	Black	Solder Lug	50000 Cycles	On-Mom	55 °C	-20 C	Green LED	2 A
E-Switch PV3WF2B0SS-335	No Marking	200000 Cycles	24 V	Panel Mount Front	Button Flush Round	IP67 - Dust Tight Waterproof	16 mm	SPDT	48 V	Anti-Vandal Illuminated	Silver	Solder Lug	50000 Cycles	On-Mom	55 °C	-20 C	Green LED	2 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Pushbutton Switch SPDT Anti-Vandal, Illuminated Panel Mount, Front
