Q-2R0550008012I

Active

Amphenol Custom Cable

COAX CBL SMA TO TNC 12"

Search across all available documentation for this part.

Active

Amphenol Custom Cable

COAX CBL SMA TO TNC 12"

Technical Specifications

Parameters and characteristics for this part

Specification	Q-2R0550008012I

1st Connector	SMA Jack, Right Angle
1st Connector Mounting Feature	Bulkhead - Front Side Nut
1st Connector Mounting Type	Panel Mount
1st Contact Gender	Female
2nd Connector	TNC Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Impedance	50 Ohms
Cable Type	RG-58
Color	Black
Connector Impedance	50 Ohms
Features	Shielded
Frequency - Max [Max]	1 GHz
Length	12 "
Length	304.8 mm
Overall Impedance	50 Ohms
Style	SMA to TNC

Part	Overall Impedance	1st Connector Mounting Feature	2nd Connector	Length	Length	1st Connector	Style	Cable Impedance	Features	Cable Type	Connector Impedance	1st Connector Mounting Type	2nd Connector Mounting Type	1st Contact Gender	2nd Contact Gender	Color	Frequency - Max [Max]
Amphenol Custom Cable Q-2R0550008012I	50 Ohms	Bulkhead - Front Side Nut	TNC Plug	12 "	304.8 mm	Right Angle SMA Jack	SMA to TNC	50 Ohms	Shielded	RG-58	50 Ohms	Panel Mount	Free Hanging (In-Line)	Female	Male	Black	1 GHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Cable Assembly Coaxial SMA to TNC RG-58 12.00" (304.80mm)

Technical documentation and resources

No documents available
