Specification	Q2-F2XYG-38-08-MS100FT

Color	Green, Yellow
Features	Flame Retardant
Inner Diameter - Recovered	0.187 in
Inner Diameter - Supplied	0.375 in
Length	100 ft
Material	Polyolefin (PO)
Operating Temperature (Max)	135 °C
Operating Temperature (Min)	-55 °C
Recovered Wall Thickness	0.022 in
Shelf Life	144 Months
Shrink Temperature	70 °C
Shrinkage Ratio	2
Storage/Refrigeration Temperature (Maximum)	104 °F
Storage/Refrigeration Temperature (Minimum)	-50 °F
Type	Flexible, Tubing

Q2-F2XYG Series

Part	Type	Inner Diameter - Supplied	Shrink Temperature	Length	Shrinkage Ratio	Features	Recovered Wall Thickness	Material	Color	Inner Diameter - Recovered	Operating Temperature (Min)	Operating Temperature (Max)	Storage/Refrigeration Temperature (Minimum)	Storage/Refrigeration Temperature (Maximum)	Shelf Life
Qualtek Q2-F2XYG-2-08-QB6IN-3	Flexible Tubing	2 in	70 °C	0.5 ft	2	Flame Retardant	0.04 in	Polyolefin (PO)	Green Yellow	1 in	-55 °C	135 °C	-50 °F	104 °F	144 Months
Qualtek Q2-F2XYG-1-08-QB6IN-8	Flexible Tubing	1 in	70 °C	0.5 ft	2	Flame Retardant	0.036 in	Polyolefin (PO)	Green Yellow	0.5 in	-55 °C	135 °C	-50 °F	104 °F	144 Months
Qualtek Q2-F2XYG-1/4-08-SS100M	Flexible Tubing	0.25 in	70 °C	328.1 ft	2	Flame Retardant	0.022 in	Polyolefin (PO)	Green Yellow	0.125 in	-55 °C	135 °C	-50 °F	104 °F	144 Months
Qualtek Q2-F2XYG-3/64-08-QB6IN-40	Flexible Tubing	0.046 in	70 °C	0.5 ft	2	Flame Retardant	0.013 in	Polyolefin (PO)	Green Yellow	0.023 in	-55 °C	135 °C	-50 °F	104 °F	144 Months
Qualtek Q2-F2XYG-38-08-MS100FT	Flexible Tubing	0.375 in	70 °C	100 ft	2	Flame Retardant	0.022 in	Polyolefin (PO)	Green Yellow	0.187 in	-55 °C	135 °C	-50 °F	104 °F	144 Months
