M7SXK-0906J

Active

D-SUB CABLE - MFM09K/MC10G/X

Search across all available documentation for this part.

Active

D-SUB CABLE - MFM09K/MC10G/X

Technical Specifications

Parameters and characteristics commom to parts in this series

D-SUB CABLE - MFM09K/MC10G/X

Part	Shielding	2nd Connector	Contact Finish Thickness	Contact Finish Thickness	Contact Finish	Number of Positions	Length	Length	1st Connector	Type	Color
3M M7SXK-0906J	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold	9	6 ft	1.83 m	Female Sockets, Receptacle	DB9
3M M7SXK-1510R	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold	15	10 ft	3.05 m	Female Sockets, Receptacle	DB15	Multiple, Ribbon
3M M7SXK-0910J	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold	9	10 ft	3.05 m	Female Sockets, Receptacle	DB9
3M M7SXK-2506R	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold		6 ft	1.83 m	Female Sockets, Receptacle	DB25	Multiple, Ribbon
3M M7SXK-3710R	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold	37	10 ft	3.05 m	Female Sockets, Receptacle	DB37	Multiple, Ribbon
3M M7SXK-2506J	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold		6 ft	1.83 m	Female Sockets, Receptacle	DB25
3M M7SXK-0906R	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold	9	6 ft	1.83 m	Female Sockets, Receptacle	DB9	Multiple, Ribbon
3M M7SXK-3710J	Unshielded	Individual Wire Leads	0.76 Ám	30 Áin	Gold	37	10 ft	3.05 m	Female Sockets, Receptacle	DB37

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

D-Sub Cable Assembly DB9 Gray, Ribbon 6.00' (1.83m) Receptacle, Female Sockets to Individual Wire Leads Unshielded
