715W-15/02
ActiveQualtek
PWR ENT RCPT IEC320-C14 PNL IDC
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 715W-15/02 |
|---|---|
| Accomodates a Fuse | False |
| Approval Agency | UL, ENEC, cUL, CCC |
| Connector Style | IEC 320-C14 |
| Connector Type | Receptacle, Female Sockets |
| Current Rating - Appliance Inlet | 10 A |
| Filter Type | Unfiltered - Commercial |
| Mounting Type | Panel Mount, Snap-In |
| Panel Cutout Dimensions [x] | 32.5 mm |
| Panel Cutout Dimensions [y] | 25 mm |
| Panel Thickness [custom] | 0.059 in |
| Panel Thickness [custom] | 1.5 mm |
| Termination | IDC |
| Voltage Rating - Appliance Inlet | 250 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 1.36 | |
| 10 | $ 1.19 | |||
| 25 | $ 1.13 | |||
| 50 | $ 1.11 | |||
| 100 | $ 1.06 | |||
| 250 | $ 0.96 | |||
| 500 | $ 0.89 | |||
Description
General part information
715W-15 Series
Power Entry Connector Receptacle, Female Sockets IEC 320-C14 Panel Mount, Snap-In
