AMI-27-36-6

Active

Altran Magnetics, LLC

LINE FILTER 250VAC 36A CHASSIS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AMI-27-36-6

Active

Altran Magnetics, LLC

LINE FILTER 250VAC 36A CHASSIS

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 86.32
		10	$ 70.39

Description

General part information

AMI-27 Series

Single Phase EMC/EMI Line Filter 36 A 250V DC ~ 400Hz Two Stage Threaded Post (M4)

Documents

Technical documentation and resources

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AMI-27-36-6	AMI-27 Series

Applications	General Purpose	Safety, General Purpose, Medical
Approval Agency	CE, cURus	CE, cURus
Configuration	Two Stage	Two Stage
Current	36 A	1 - 36 A
Filter Type	Single Phase	Single Phase
Frequency - Operating	400 Hz	400 Hz
Inductance	-	2.46 - 44 mH
Mounting Type	Chassis Mount	Chassis Mount
Operating Temperature [custom]	100 °C, -25 °C	-25 - 100 °C
Termination Style	Threaded Post (M4)	Quick Connect, Threaded Post (M4)
Voltage - Rated AC	250 V	250 V

AMI-27 Series

LINE FILTER 250VAC 12A CHASSIS

Part	Configuration	Current	Applications	Operating Temperature [custom]	Approval Agency	Mounting Type	Filter Type	Frequency - Operating	Inductance	Voltage - Rated AC	Termination Style
Altran Magnetics, LLC AMI-27A-12-3	Two Stage	12 A	Safety	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	6.5 mH	250 V	Quick Connect
Altran Magnetics, LLC AMI-27A-16-3	Two Stage	16 A	Safety	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	5.6 mH	250 V
Altran Magnetics, LLC AMI-27-12-3	Two Stage	12 A	General Purpose	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	6.5 mH	250 V	Quick Connect
Altran Magnetics, LLC AMI-27B-1-3	Two Stage	1 A	Medical	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	44 mH	250 V	Quick Connect
Altran Magnetics, LLC AMI-27-36-6	Two Stage	36 A	General Purpose	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz		250 V	Threaded Post (M4)
Altran Magnetics, LLC AMI-27-3-3	Two Stage	3 A	General Purpose	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz		250 V	Quick Connect
Altran Magnetics, LLC AMI-27B-3-3	Two Stage	3 A	Medical	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	19.6 mH	250 V	Quick Connect
Altran Magnetics, LLC AMI-27A-10-3	Two Stage	10 A	Safety	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	9 mH	250 V	Quick Connect
Altran Magnetics, LLC AMI-27B-6-1	Two Stage	6 A	Medical	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	15.6 mH	250 V	Quick Connect
Altran Magnetics, LLC AMI-27-10-1	Two Stage	10 A	General Purpose	-25 °C, 100 °C	CE, cURus	Chassis Mount	Single Phase	400 Hz	9 mH	250 V	Quick Connect
