5962-8766001PA
ActiveAnalog Devices Inc./Maxim Integrated
IC GATE DRVR HALF-BRIDGE 8CERDIP
Deep-Dive with AI
Search across all available documentation for this part.
5962-8766001PA
ActiveAnalog Devices Inc./Maxim Integrated
IC GATE DRVR HALF-BRIDGE 8CERDIP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 5962-8766001PA |
|---|---|
| Channel Type | Independent |
| Driven Configuration | Half-Bridge |
| Gate Type | N-Channel MOSFET |
| Input Type | Inverting |
| Logic Voltage - VIL, VIH | 0.8 V, 2 V |
| Mounting Type | Through Hole |
| Number of Drivers | 2 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 7.62 mm |
| Package / Case | 0.3 in |
| Package / Case | 8-CDIP |
| Rise / Fall Time (Typ) [custom] | 20 ns |
| Rise / Fall Time (Typ) [custom] | 20 ns |
| Supplier Device Package | 8-CERDIP |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
5962-8766001 Series
IC GATE DRVR HALF-BRIDGE 8CERDIP
| Part | Driven Configuration | Input Type | Logic Voltage - VIL, VIH | Mounting Type | Gate Type | Supplier Device Package | Number of Drivers | Channel Type | Package / Case | Package / Case | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Rise / Fall Time (Typ) [custom] | Rise / Fall Time (Typ) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated 5962-8766001PA | Half-Bridge | Inverting | 0.8 V, 2 V | Through Hole | N-Channel MOSFET | 8-CERDIP | 2 | Independent | 7.62 mm | 0.3 in | 8-CDIP | -55 °C | 125 °C | 20 ns | 20 ns |
Description
General part information
5962-8766001 Series
Half-Bridge Gate Driver IC Inverting 8-CERDIP
