RA1H1C112R

Active

E-Switch

SWITCH ROCKER SPST 16A 125V

Search across all available documentation for this part.

Active

E-Switch

SWITCH ROCKER SPST 16A 125V

Technical Specifications

Parameters and characteristics for this part

Specification	RA1H1C112R

Actuator Marking	O I
Actuator Type	Concave (Curved)
Approval Agency	cULus
Circuit	SPST
Color - Actuator/Cap	Black
Current Rating (Amps)	16 A
Electrical Life	10000 Cycles
Mounting Type	Snap-In, Right Angle, Panel Mount
Operating Temperature [Max]	55 °C
Operating Temperature [Min]	-20 C
Panel Cutout Dimensions [x]	19.4 mm
Panel Cutout Dimensions [y]	13.1 mm
Switch Function	On-Off
Termination Style	PC Pin
Voltage Rating - AC	125 V

Part	Actuator Marking	Actuator Type	Circuit	Switch Function	Current Rating (Amps)	Electrical Life	Termination Style	Mounting Type	Color - Actuator/Cap	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Operating Temperature [Max]	Operating Temperature [Min]	Approval Agency	Voltage Rating - AC
E-Switch RA1H1C112R	O I	Concave (Curved)	SPST	On-Off	16 A	10000 Cycles	PC Pin	Panel Mount Right Angle Snap-In	Black	13.1 mm	19.4 mm	55 °C	-20 C	cULus	125 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Rocker Switch SPST 16A (AC) 125 V Panel Mount, Snap-In, Right Angle

Technical documentation and resources

No documents available
