924-3/4"X36YD-BULK

Active

3M (TC)

TAPE ADHSV TRNSFR CLR 3/4"X36YDS

Search across all available documentation for this part.

Active

3M (TC)

TAPE ADHSV TRNSFR CLR 3/4"X36YDS

Technical Specifications

Parameters and characteristics for this part

Specification	924-3/4"X36YD-BULK

Adhesive	Acrylic
Backing, Carrier	Paper
Color	Clear
Length	36 yd
Length	32.9 m
Length	108 ft
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	69.8 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Adhesive Transfer
Temperature Range [Max]	38 °C
Temperature Range [Max]	100 °F
Temperature Range [Min]	21 °C
Temperature Range [Min]	70 °F
Thickness	0.05 mm
Thickness	0.002 in
Thickness	2 mils
Width	0.75 in
Width	19.05 mm
Width	0.75 in

Part	Thickness	Thickness	Thickness	Adhesive	Width	Width	Width	Color	Length	Length	Length	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Shelf Life	Shelf Life Start	Usage	Backing, Carrier	Tape Type	Temperature Range	Temperature Range	Temperature Range [Max]	Temperature Range [Min]	Temperature Range [Max]	Temperature Range [Min]
3M (TC) 924-3/4"X60YD	2 mils	0.002 in	0.051 mm	Acrylic 400	0.75 in	19.05 mm	0.75 in	Clear	60 yds	55 m	180 ft	70 °F	21 °C	24 Months	Date of Manufacture	General Purpose	Densified Kraft	Adhesive Transfer	82 °C	180 °F
3M (TC) 924-3/4"X36YD-BULK	2 mils	0.002 in	0.05 mm	Acrylic	0.75 in	19.05 mm	0.75 in	Clear	36 yd	32.9 m	108 ft	69.8 °F	21 °C	24 Months	Date of Manufacture		Paper	Adhesive Transfer			38 °C	21 °C	100 °F	70 °F
3M (TC) 924-1/4"X36YD	2 mils	0.002 in	0.051 mm	Acrylic 400	0.25 in	0.25 in	6.35 mm	Clear	36 yd	32.9 m	108 ft	70 °F	21 °C	24 Months	Date of Manufacture	General Purpose	Densified Kraft	Adhesive Transfer	82 °C	180 °F
3M (TC) 924-3/4"X36YD-BOX	2 mils	0.002 in	0.051 mm	Acrylic 400	0.75 in	19.05 mm	0.75 in	Clear	36 yd	32.9 m	108 ft	70 °F	21 °C	24 Months	Date of Manufacture	General Purpose	Densified Kraft	Adhesive Transfer	82 °C	180 °F

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	48	$ 13.15

General part information

Adhesive Transfer Tape Acrylic Adhesive Clear 0.75" (19.05mm) 3/4" X 108' (32.9m) 36 yds

Technical documentation and resources
