C961-NWR24H-CWO
ActiveVisual Communications Company - VCC
PMI ROUND LED .290" 24V HI-HAT P
Deep-Dive with AI
Search across all available documentation for this part.
C961-NWR24H-CWO
ActiveVisual Communications Company - VCC
PMI ROUND LED .290" 24V HI-HAT P
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | C961-NWR24H-CWO |
|---|---|
| Lamp Color | Red |
| Lens Color | Colorless |
| Lens Size [diameter] | 7.1 mm |
| Lens Transparency | Clear |
| Millicandela Rating | 2800 mcd |
| Panel Cutout Dimensions [x] | 7.37 mm |
| Panel Cutout Dimensions [x] | 0.29 in |
| Panel Cutout Shape | Round |
| Termination Style | 0.201 in |
| Termination Style | Wire Wrap |
| Termination Style | 5.1 mm |
| Type | LED |
| Viewing Angle | 30 ° |
| Voltage | 24 V |
| Wavelength - Peak | 634 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 100 | $ 7.64 | |
Description
General part information
C961-NWR24 Series
LED Panel Indicator Red Clear 30° 24V 20mA Wire Wrap, 0.201" (5.1mm)
Documents
Technical documentation and resources
No documents available
