FN356-150-28

Obsolete

TE Connectivity Raychem Cable Protection

LINE FILTER 150A CHASSIS MOUNT

Search across all available documentation for this part.

Obsolete

TE Connectivity Raychem Cable Protection

LINE FILTER 150A CHASSIS MOUNT

Technical Specifications

Parameters and characteristics for this part

Specification	FN356-150-28

Applications	General Purpose
Approval Agency	CSA, ENEC, UR
Configuration	Single Stage
Current	150 A
Filter Type	Three Phase (Wye)
Frequency - Operating [Max]	60 Hz
Frequency - Operating [Min]	DC
Mounting Type	Chassis Mount
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Threaded Post (M10)
Voltage - Rated AC (Phase to Ground/Neutral)	250 V
Voltage - Rated AC (Phase to Phase)	440 V

Part	Current	Termination Style	Mounting Type	Approval Agency	Operating Temperature [custom]	Voltage - Rated AC (Phase to Phase)	Configuration	Applications	Voltage - Rated AC (Phase to Ground/Neutral)	Filter Type	Frequency - Operating [Max]	Frequency - Operating [Min]
TE Connectivity Raychem Cable Protection FN356-25-24	25 A	Threaded Post (M6)	Chassis Mount	CSA ENEC UR	-25 °C 100 °C	440 V	Single Stage	General Purpose	250 V	Three Phase (Wye)	60 Hz	DC
TE Connectivity Raychem Cable Protection FN356-50-24	50 A	Threaded Post (M6)	Chassis Mount	CSA ENEC UR	-25 °C 100 °C	440 V	Single Stage	General Purpose	250 V	Three Phase (Wye)	60 Hz	DC
TE Connectivity Raychem Cable Protection FN356-50-33	50 A	Terminal Block	Chassis Mount	CSA ENEC UR	-25 °C 100 °C	440 V	Single Stage	General Purpose	250 V	Three Phase (Wye)	60 Hz	DC
TE Connectivity Raychem Cable Protection FN356-36-24	36 A	Threaded Post (M6)	Chassis Mount	CSA ENEC UR	-25 °C 100 °C	440 V	Single Stage	General Purpose	250 V	Three Phase (Wye)	60 Hz	DC
TE Connectivity Raychem Cable Protection FN356-16-29	16 A	Terminal Block	Chassis Mount	CSA ENEC UR	-25 °C 100 °C	440 V	Single Stage	General Purpose	250 V	Three Phase (Wye)	60 Hz	DC
TE Connectivity Raychem Cable Protection FN356-36-33	36 A	Terminal Block	Chassis Mount	CSA ENEC UR	-25 °C 100 °C	440 V	Single Stage	General Purpose	250 V	Three Phase (Wye)	60 Hz	DC
TE Connectivity Raychem Cable Protection FN356-150-28	150 A	Threaded Post (M10)	Chassis Mount	CSA ENEC UR	-25 °C 100 °C	440 V	Single Stage	General Purpose	250 V	Three Phase (Wye)	60 Hz	DC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 1061.59

General part information

Three Phase (Wye) EMC/EMI Line Filter 150 A DC ~ 60Hz Single Stage Threaded Post (M10)
