7957A 0021000
ActiveBelden Inc.
CABLE CAT5E 8CON 24AWG RED
Deep-Dive with AI
Search across all available documentation for this part.
7957A 0021000
ActiveBelden Inc.
CABLE CAT5E 8CON 24AWG RED
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 7957A 0021000 |
|---|---|
| Cable Type | Multi-Pair, Cat5e |
| Conductor Insulation | Polyolefin (PO) |
| Conductor Material | Copper, Bare |
| Conductor Strand | Solid |
| Features | Oil Resistant, UV Resistant, Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.33 in |
| Jacket (Insulation) Diameter [diameter] | 8.38 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Red |
| Length | 1000 ft |
| Length | 304.8 m |
| Number of Conductors | 8 |
| Operating Temperature [Max] | 75 ░C |
| Operating Temperature [Min] | -40 °C |
| Ratings | UL Style CMR |
| Shield Coverage | 70 %, 100 % |
| Shield Material | Copper, Tinned, Aluminum |
| Shield Type | Foil, Braid |
| Usage | Industrial, Network |
| Wire Gauge | 24 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1000 | $ 3.23 | |
Description
General part information
7957A Series
8 (4 Pair Twisted) Conductor Multi-Pair, Cat5e Cable Red 24 AWG Foil, Braid 1000.0' (304.8m)
