MX5-26S-C-G

Obsolete

JAE Electronics

CONN RCPT HSG 26POS 3.00MM

Search across all available documentation for this part.

Obsolete

JAE Electronics

CONN RCPT HSG 26POS 3.00MM

Technical Specifications

Parameters and characteristics for this part

Part	Style	Contact Material	Contact Type	Number of Rows	Insulation Height	Insulation Height	Insulation Color	Shrouding	Features	Contact Shape	Mounting Type	Contact Finish - Post	Fastening Type	Contact Length - Post	Contact Length - Post	Number of Positions Loaded	Connector Type	Number of Positions	Termination	Insulation Material	Contact Length - Mating	Contact Length - Mating	Pitch [x]	Pitch [x]	Contact Termination	Color	Note
JAE Electronics MX5-26P-L-G-C10	Board to Cable/Wire	Brass	Male Pin	2	21.89 mm	0.862 in	Green	Shrouded - 4 Wall	Mounting Flange	Square	Through Hole Right Angle	Tin	Locking Ramp	0.157 in	4 mm	All	Header	26	Solder	Polybutylene Terephthalate (PBT) Glass Filled	7.21 mm	0.284 in
JAE Electronics MX5-26S-C-G			Female Socket	2							Free Hanging (In-Line)						Receptacle	26					3 mm	0.118 in	Crimp	Green	Contacts Not Included

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

26 Rectangular Connectors - Housings Receptacle Green 0.118" (3.00mm)
