08025SA-24N-ET-00

Obsolete

NMB TECHNOLOGIES

FAN AXIAL 80X25MM 24VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsFan Part Numbering Guide Fan Agency Approvals +2

08025SA-24N-ET-00

Obsolete

NMB TECHNOLOGIES

FAN AXIAL 80X25MM 24VDC WIRE

Deep-Dive with AI

DocumentsFan Part Numbering Guide Fan Agency Approvals +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	08025SA-24N-ET-00

Air Flow	41.3 CFM
Air Flow	1.16 mł/min
Approval Agency	UL, CE, VDE, CSA
Bearing Type	Ball
Fan Type	Tubeaxial
Features	Speed Sensor (Tach)
Lifetime @ Temp.	40000 Hrs
Material - Blade	Plastic
Material - Frame	Plastic
Noise	30 dB(A)
Operating Temperature [Max]	70 °C
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-10 °C
Operating Temperature [Min]	-10 °C
Power (Watts)	1.92 W
RPM	3100 RPM
Size / Dimension [x]	80 mm
Size / Dimension [y]	80 mm
Static Pressure	0.15 in H2O
Static Pressure	37.4 Pa
Termination	3 Wire Leads
Voltage - Rated	24 VDC
Voltage Range [Max]	27.6 VDC
Voltage Range [Min]	12 VDC
Weight	0.176 lb
Weight	79.83 g
Width [y]	25 mm

08025SA Series

Part	Lifetime @ Temp.	Weight	Weight	Size / Dimension [y]	Size / Dimension [x]	Material - Blade	Fan Type	Approval Agency	Voltage - Rated	Bearing Type	Width [y]	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Material - Frame	Termination	Noise	Voltage Range [Max]	Voltage Range [Min]	Static Pressure	Static Pressure	RPM	Air Flow	Air Flow	Current Rating (Amps)	Features	Power (Watts)
NMB TECHNOLOGIES 08025SA-24Q-EA-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	24 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	2 Wire Leads
NMB TECHNOLOGIES 08025SA-24R-EA-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	24 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	2 Wire Leads	42 dB	26.4 VDC	12 VDC	0.33 in H2O	82.2 Pa	4500 RPM	60 CFM	1.68 mł/min	0.17 A
NMB TECHNOLOGIES 08025SA-24P-EA-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	24 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	2 Wire Leads
NMB TECHNOLOGIES 08025SA-12P-EL-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	12 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	3 Wire Leads										Locked Rotor Sensor
NMB TECHNOLOGIES 08025SA-12P-AA-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	12 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	2 Wire Leads
NMB TECHNOLOGIES 08025SA-12M-AT-D0	100000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	12 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	3 Wire Leads	26 dB	13.8 VDC	6 VDC	0.116 in H2O	29 Pa	2700 RPM	36 CFM	1.01 m³/min	0.09 A	Speed Sensor (Tach)	1.08 W
NMB TECHNOLOGIES 08025SA-12R-AL-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	12 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	3 Wire Leads	42 dB	13.8 VDC	7 V	0.33 in H2O	82.2 Pa	4500 RPM	60 CFM	1.68 mł/min	320 mA	Locked Rotor Sensor	3.84 W
NMB TECHNOLOGIES 08025SA-24R-AL-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	24 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	3 Wire Leads	42 dB	26.4 VDC	12 VDC	0.33 in H2O	82.2 Pa	4500 RPM	60 CFM	1.68 mł/min	0.17 A	Locked Rotor Sensor
NMB TECHNOLOGIES 08025SA-24N-ET-00	40000 Hrs	0.176 lb	79.83 g	80 mm	80 mm	Plastic	Tubeaxial	CE CSA UL VDE	24 VDC	Ball	25 mm	70 °C	70 °C	-10 °C	-10 °C	Plastic	3 Wire Leads	30 dB(A)	27.6 VDC	12 VDC	0.15 in H2O	37.4 Pa	3100 RPM	41.3 CFM	1.16 mł/min		Speed Sensor (Tach)	1.92 W

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 9.51
		10	$ 9.08
		25	$ 8.54
		80	$ 8.21
		160	$ 7.56

Description

General part information

08025SA Series

Fan Tubeaxial 24VDC Square - 80mm L x 80mm H Ball 41.3 CFM (1.16m³/min) 3 Wire Leads
